Memory-Mapped TI Proprietary Register Space

109

November 2005

SCPS097B

Memory-Mapped TI Proprietary Register Space

The programming model of the memory-mapped TI proprietary register space is unique to this device. These

custom registers are specifically designed to provide enhanced features associated with upstream

isochronous applications.

All bits marked with a k are sticky bits and are reset by a global reset (GRST) or the internally-generated

power-on reset. All bits marked with a † are reset by a PCI Express reset (PERST), a GRST or the

internally-generated power-on reset. The remaining register bits are reset by a PCI Express hot reset, PERST,

GRST, or the internally-generated power-on reset.

Table 6−1. Device Control Memory Window Register Map

OFFSET

Upstream isochrony capabilities

Revision ID

Device control map ID

00h

Reserved

Upstream isochrony control

04h

Reserved

Upstream isochronous window 0 control

08h

Upstream isochronous window 0 base address

0Ch

Upstream isochronous window 0 limit

10h

Reserved

Upstream isochronous window 1 control

14h

Upstream isochronous window 1 base address

18h

Upstream isochronous window 1 limit

1Ch

Reserved

Upstream isochronous window 2 control

20h

Upstream isochronous window 2 base address

24h

Upstream isochronous window 2 limit

28h

Reserved

Upstream isochronous window 3 control

2Ch

Upstream isochronous window 3 base address

30h

Upstream isochronous window 3 limit

34h

Reserved

38h−3Ch

GPIO data†

GPIO control†

40h

Serial-bus control and status†

Serial-bus slave address†

Serial-bus word address†

Serial-bus data†

44h

Serial IRQ edge control†

Reserved

Serial IRQ mode control†

48h

Reserved

Serial IRQ status

4Ch

† One or more bits in this register are reset by a PCI Express reset (PERST), a GRST, or the internally-generated power-on reset.

6.1

Device Control Map ID Register

The device control map ID register identifies the TI proprietary layout for this device control map. The value

01h identifies this as a PCI Express-to-PCI bridge supporting upstream isochronous capabilities.

Device control memory window register offset:

00h

Read-only

Default value:

01h

BIT NUMBER

RESET STATE
