background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 94 of 109
14.7
Low Voltage Detector Characteristics
[1]: valid for all devices except devices listed under “[2]”
[2]: valid for: MB96F345
CILCR:LVL[3:0] are the low voltage detector level select bits of the CILCR register.
Levels 10 to 15 are not used in this device.
For correct detection, the slope of the voltage level must satisfy
.
Faster variations are regarded as noise and may not be detected.
The functional operation of the MCU is guaranteed down to the minimum low voltage detection level of Vcc = 2.7V. The electrical
characteristics however are only valid in the specified range (usually down to 3.0V).
(TA = -40 °C to +125 °C, Vcc = AVcc = 3.0V - 5.5V, Vss = AVss = 0V)
Parameter
Symbol
Value [1]
Value [2]
Unit
Remarks
Min
Max
Min
Max
Stabilization time
TLVDSTAB
-75-
110
s
After power-up or change of
detection level
Level 0
VDL0
2.7
2.9
2.65
2.95
V
CILCR:LVL[3:0]=”0000”
Level 1
VDL1
2.9
3.1
2.85
3.2
V
CILCR:LVL[3:0]=”0001”
Level 2
VDL2
3.1
3.3
3.05
3.4
V
CILCR:LVL[3:0]=”0010”
Level 3
VDL3
3.5
3.75
3.45
3.85
V
CILCR:LVL[3:0]=”0011”
Level 4
VDL4
3.6
3.85
3.55
3.95
V
CILCR:LVL[3:0]=”0100”
Level 5
VDL5
3.7
3.95
3.65
4.1
V
CILCR:LVL[3:0]=”0101”
Level 6
VDL6
3.8
4.05
3.75
4.2
V
CILCR:LVL[3:0]=”0110”
Level 7
VDL7
3.9
4.15
3.85
4.3
V
CILCR:LVL[3:0]=”0111”
Level 8
VDL8
4.0
4.25
3.95
4.4
V
CILCR:LVL[3:0]=”1000”
Level 9
VDL9
4.1
4.35
4.05
4.5
V
CILCR:LVL[3:0]=”1001”
Level 10
VDL10
not used
not used
Level 11
VDL11
not used
not used
Level 12
VDL12
not used
not used
Level 13
VDL13
not used
not used
Level 14
VDL14
not used
not used
Level 15
VDL15
not used
not used
t
d
dV
0.004
V
s
------
