MB96F348CWCPMC-GSE2 datasheet(7/109 Pages) CYPRESS

7 / 109 page

MB96340 Series

Document Number: 002-04579 Rev. *A

Page 7 of 109

[1]: These devices are under development and specification is preliminary. These products under development may change its

specification without notice.

I2C

2 channels

A/D Converter

40 channels

24 channels

A/D Converter Reference Voltage

switch

yes

yes (except MB96F345Dyy or MB96F345Fyy)

16-bit Reload Timer

6 channels + 1

channel (for PPG)

4 channels + 1 channel (for PPG)

16-bit Free-Running Timer

4 channels

2 channels

16-bit Output Compare

12 channels

8 channels

16-bit Input Capture

12 channels

8 channels

16-bit Programmable Pulse

Generator

20 channels

16 channels

CAN Interface

5 channels

MB96(F)34xAyy or MB96(F)34xCyy: no

MB96F345Dyy or MB96F345Fyy: 1 channel

others: 2 channels

External Interrupts

16 channels

Non-Maskable Interrupt

1 channel

Real Time Clock

I/O Ports

136

80 for part number with suffix "W", 82 for part number with suffix "S"

Alarm comparator

2 channels

MB96F345Dyy or MB96F345Fyy: no

others: 2 channels

External bus interface

Yes

Yes (multiplexed address/data)

Chip select

6 signals

Clock output function

2 channels

Low voltage reset

Yes

On-chip RC-oscillator

Yes

Features

MB96V300B

MB96(F)34x
