MB96F348CWCPMC-GSE2 datasheet(60/109 Pages) CYPRESS

60 / 109 page

MB96340 Series

Document Number: 002-04579 Rev. *A

Page 60 of 109

[4]: The maximum permitted power dissipation depends on the ambient temperature, the air flow velocity and the thermal

conductance of the package on the PCB.The actual power dissipation depends on the customer application and can be calculated

as follows:

PD = PIO + PINT

PIO = (VOL * IOL + VOH * IOH) (IO load power dissipation, sum is performed on all IO ports)

PINT = VCC * (ICC + IA) (internal power dissipation)

ICC is the total core current consumption into VCC as described in the “DC characteristics” and depends on the selected operation

mode and clock frequency and the usage of functions like Flash programming or the clock modulator.IA is the analog current

consumption into AVCC.

[5]: Worst case value for a package mounted on single layer PCB at specified TA without air flow.

[6]: Please contact Cypress for reliability limitations when using under these conditions.

WARNING: Semiconductor devices can be permanently damaged by application of stress (voltage, current, temperature, etc.) in

excess of absolute maximum ratings. Do not exceed any of these ratings.

14.2

Recommended Operating Conditions

WARNING: The recommended operating conditions are required in order to ensure the normal operation of the semiconductor

device. All of the device's electrical characteristics are warranted when the device is operated within these ranges.

Always use semiconductor devices within their recommended operating condition ranges. Operation outside these

ranges may adversely affect reliability and could result in device failure.

No warranty is made with respect to uses, operating conditions, or combinations not represented on the data sheet.

Users considering application outside the listed conditions are advised to contact their representatives beforehand.

Parameter

Symbol

Value

Unit

Remarks

Min

Typ

Max

Power supply voltage

VCC

3.0

5.5

Smoothing capacitor at C pin

3.5

4.7 - 10

F

Use a low inductance capacitor

(for example X7R ceramic capacitor)
