Maximum ratings

Stressing the device outside the ratings listed in Table 8 may cause permanent damage to the device. These

are stress ratings only, and operation of the device at these, or any other conditions outside those indicated in

the operating sections of this specification, is not implied. Exposure to absolute maximum rating conditions for

extended periods may affect device reliability.

Table 8. Absolute maximum ratings

Symbol

Parameter

Min.

Max.

Unit

TAMB

Ambient operating temperature

–40

130

°C

TSTG

Storage temperature

–65

150

TLEAD

Lead temperature during soldering

See note (1)

Output voltage

–0.50

VCC + 0.6

Input voltage

–0.50

6.5

VCC

Supply voltage

–0.50

6.5

IOL

DC output current (Q = 0)

IOH

DC output current (Q = 1)

VESD

Electrostatic discharge voltage (human body model) (2)

4000

1. Compliant with JEDEC standard J-STD-020 (for small-body, Sn-Pb or Pb free assembly), the ST ECOPACK 7191395

specification, and the European directive on Restrictions on Hazardous Substances (RoHS directive 2011/65/EU of July

2011).

2. Positive and negative pulses applied on different combinations of pin connections, according to AEC-Q100-002 (compliant

with ANSI/ESDA/JEDEC JS-001-2012, C1 = 100 pF, R1 = 1500 Ω, R2 = 500 Ω).

M95256-W M95256-R M95256-DF

Maximum ratings

DS4712 - Rev 22

page 27/51
