48 / 52 page

A22NE-PD/A22NE-P/A22E

2.3 +0.5

-1.5

Switch Mounting Dimension

2.3 +0.5

-1.5

Switch Mounting

Dimension

Sunken

section,

0.2

Switch guard

2.8

20.5

90 dia.

78 dia.

52.2 max.

30 40

75 min.

(Determined by the

height of the Switch

surface in the

lock position.)

22.2 dia

33 dia.

Panel Cutout Dimensions

EMERGENCY OFF

inscription plate (t=1)

Rubber packing (t=0.5)

Locking ring

Mounting panel

2 1

Panel

Switch Unit

A22E-M

2.5+0.5

-1.5

R1.7+0.1

22.3+0.4

dia.

24.2±0.2

“EMERGENCY STOP” is indicated

on A22Z-EG1-W.

Legend plate is not provided with

A22Z-EG10 and A22Z-EG10-W.

8.5

52.2 max.

30 dia.

40 dia.

1-pole

Switch Unit

2-pole

Switch Unit

38.5

37 max.

Panel

Screw Terminal Block type

Mounting a 1-pole Switch Unit

Push-in Plus Terminal Block type

Mounting a 1-pole Switch Unit

Push-in Plus Terminal Block type

Mounting a 2-pole Switch Unit

Note: 1. The dimensions of the

Shroud conform to the

specifications of the

SEMATECH

Application Guide for

SEMI S2-93.

2. The Shroud is not

provided with the

Switch.

Common E-stop Shrouds

A22Z-EG1, A22Z-EG1-W, A22Z-EG10, A22Z-EG10-W

Model

Allowable panel

thickness [mm]

A22NE-PD series

1 to 1.8

A22NE-P series

1 to 2.0

A22E series
