Data Sheet

ADL8142

ABSOLUTE MAXIMUM RATINGS

analog.com

Rev. 0 | 4 of 20

Table 4.

Parameter

Rating

VDD

4.5 V

RF Input Power (RFIN)

20 dBm

Pulsed RFIN (Duty Cycle = 10%, Pulse Width = 100 μs) 22 dBm

Continuous Power Dissipation (PDISS), TCASE = 85°C

(Derate 5.99 mW/°C Above 85°C)

0.54 W

Temperature

Storage Range

−65°C to +150°C

Operating Range

−40°C to +85°C

Nominal Junction (TA = 85°C, VDD = 2 V, IDQ = 25

mA, Input Power (PIN) = Off)

93.4°C

Maximum Junction

175°C

Stresses at or above those listed under Absolute Maximum Ratings

may cause permanent damage to the product. This is a stress

rating only; functional operation of the product at these or any other

conditions above those indicated in the operational section of this

specification is not implied. Operation beyond the maximum operat-

ing conditions for extended periods may affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to printed circuit board

(PCB) design and operating environment. Close attention to PCB

thermal design is required.

θJC is the junction to case thermal resistance.

Table 5. Thermal Resistance

Package Type

θJC

Unit

CP-8-30

Quiescent, TBASE = 25°C

134.3

°C/W

Worst Case1, TBASE = 85°C

167

°C/W

1 Worst case across all specified operating conditions

ELECTROSTATIC DISCHARGE (ESD) RATINGS

The following ESD information is provided for handling of ESD-sen-

sitive devices in an ESD protected area only.

Human body model (HBM) per ANSI/ESDA/JEDEC JS-001.

ESD Ratings for ADL8142

Table 6. ADL8142, 8-Lead LFCSP

ESD Model

Withstand Threshold (V)

Class

HBM

±250

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Charged devi-

ces and circuit boards can discharge without detection. Although

this product features patented or proprietary protection circuitry,

damage may occur on devices subjected to high energy ESD.

Therefore, proper ESD precautions should be taken to avoid

performance degradation or loss of functionality.
