Data Sheet

ADL8142

SPECIFICATIONS

analog.com

Rev. 0 | 3 of 20

23 GHZ TO 27 GHZ FREQUENCY RANGE

Supply voltage (VDD) = 2 V, quiescent current (IDQ) = 25 mA, bias resistance (RBIAS) = 634 Ω, and TC = 25°C, unless otherwise noted.

Table 1.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY RANGE

GHz

GAIN

Gain Variation over Temperature

0.073

dB/°C

NOISE FIGURE

1.8

RETURN LOSS

Input (S11)

10.5

Output (S22)

OUTPUT

Power for 1 dB Compression (P1dB)

8.5

dBm

Saturated Power (PSAT)

dBm

IP3

17.5

dBm

Measurement taken at output power (POUT) per tone = −4 dBm

Second-Order Intercept (IP2)

dBm

Measurement taken at POUT per tone = −4 dBm

POWER ADDED EFFICIENCY (PAE)

Measured at PSAT

27 GHZ TO 31 GHZ FREQUENCY RANGE

VDD = 2 V, IDQ = 25 mA, RBIAS = 634 Ω, and TC = 25°C, unless otherwise noted.

Table 2.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY RANGE

GHz

GAIN

24.5

Gain Variation over Temperature

0.037

dB/°C

NOISE FIGURE

1.6

RETURN LOSS

S11

S22

OUTPUT

P1dB

7.5

dBm

PSAT

dBm

IP3

dBm

Measurement taken at POUT per tone = −4 dBm

IP2

dBm

Measurement taken at POUT per tone = −4 dBm

PAE

Measured at PSAT

DC SPECIFICATIONS

Table 3.

Parameter

Min

Typ

Max

Unit

SUPPLY CURRENT

IDQ

Amplifier Current (IDQ_AMP)

RBIAS Current (IRBIAS)

SUPPLY VOLTAGE

VDD

1.5

3.5
