8.2

User modes

8.2.1

Standard modes

The output parallel interface outputs12 bits of data, HSYNC, VSYNC, and PCLK. It is recommended to enable the

compensation macro (controlled by Mode_Reg3[5], at address 0x36) for both Standard and Bypass modes.

CSI2/CSI2

•

Main camera: CSI2 up to 1.6 Gbps (with limitation detailed in Section 8.3 CSI2 limitations)

•

Second camera: CSI2 up to 800 Mbps

CSI2/CCP2

•

Main camera: CSI2 up to 1.6 Gbps (with limitation detailed in Section 8.3 CSI2 limitations)

•

Second camera: CCP2 up to 650 Mbps

CSI2/ITU-R601

•

Main camera: CSI2 up to 1.6 Gbps (with limitation detailed in Section 8.3 CSI2 limitations)

•

Second camera: YUV directly connected to baseband parallel interface

8.2.2

Bypass modes

Bypass mode is used for any activities or applications where only PHY is needed, example, 8-bit data.

CSI2/CSI2

•

Main camera: CSI2 up to 1.6 Gbps (with limitation detailed in Section 8.3 CSI2 limitations)

•

Second camera: CSI2 up to 800 Mbps

CSI2/ ITU-R601

•

Main camera: CSI2 up to 1.6 Gbps (with limitation detailed in Section 8.3 CSI2 limitations)

•

Second camera: YUV directly connected to baseband parallel interface

8.3

CSI2 limitations

The bandwidth is limited to 800 Mbps in RAW6/RAW7 dual lane inputs. This is irrespective of the compression

used or not

STMIPID02

User modes

DS12803 - Rev 1

page 13/50
