41 | Keysight | Infiniium Z-Series Oscilloscopes - Data Sheet

Hardware trigger (Continued)

Measurement modes

Automatic measurements

Measure menu access to all measurements, up to 20 measurements can be displayed simultaneously

Multipurpose

Front-panel button activates up to ten pre-selected or up to ten user-defined automatic measurements

Drag-and-drop measurement

toolbar

Measurement toolbar with common measurement icons that can be dragged and dropped onto the displayed

waveforms

Marker modes

Manual markers, track waveform data, track measurements

Bookmarks and callouts

Supports callouts for measurements and FFT peaks. Supports bookmarks for team collaboration

Display

Display

15.4-inch color XGA TFT-LCD with capacitive touch screen

Intensity grayscale

256-level intensity-graded display

Resolution XGA

1024 pixels horizontally x 768 pixels vertically

Annotation

Up to 100 bookmarks can be inserted into the waveform window. Each can float or be tied to a specific waveform

Grids

Choose between 1-16 grids per waveform area, 8 bit vertical resolution

Waveform styles

Connected dots, dots, infinite persistence, color graded infinite persistence. Includes up to 256 levels of intensity-

graded waveforms., variable persistence

Waveform area

Supports eight waveform areas plus chart mode for EZJIT Plus, InfiniiSim, protocol, and PrecisionProbe

Maximum update rate

> 400,000 waveforms per second (when in the segment memory mode)

Computer system and peripherals, I/O ports

Computer system and peripherals

Operating system

Windows 7 64-bit

CPU

Intel i5-3550S quad-core CPU at 3.00 GHz

PC system memory

16 GB DDR3 RAM

Drives (SSD)

500-GB internal hard drive removable hard drive, additional hard drives (N2110A)

Peripherals

Logitech optical USB mouse, compact USB keyboard supplied. All Infiniium models support any Windows-

compatible input device with a serial, PS/2 or USB interface.

File types

Waveforms

Compressed internal format (*.wfm (200 Mpts)), comma-separated values (*.csv (2 Gpts)), tab-separated values

(*.tsv (2 Gpts)), public binary format (.bin (500 Mpts)), Y value files (*.txt (2 Gpts)), hierarchal data file (*.hf5 (2 Gpts)),

composite data file (*.osc (2 Gpts))

Images

BMP, PNG, TIFF, GIF, JPEG or osc file format

I/O ports

RS-232 (serial), parallel, PS/2, USB 2.0 hi-speed (host), USB 2.0 hi-speed (device), VGA, DisplayPort, USB 3.0,

dual-monitor video output, auxiliary output, trigger output, time base reference output

Specifications (Continued)
