2.7. RF Electrical Characteristics

2.7.1. Receive

Table 2.8 lists the key parameters of the integrated IEEE 802.15.4-2003 receiver on the EM35x.

Receive measurements were collected with the Silicon Labs EM35x Ceramic Balun Reference Design (Version

A0) at 2440 MHz. The typical number indicates one standard deviation above the mean, measured at room

temperature (25

C). The min and max numbers were measured over process corners at room temperature.

Table 2.8. Receive Characteristics

Parameter

Test Condition

Min

Typ

Max

Unit

Frequency range

2400

—

2500

MHz

Sensitivity (boost mode)

1% PER, 20 byte packet defined by

IEEE 802.15.4-2003;

—

–102

–96

dBm

Sensitivity

1% PER, 20 byte packet defined by

IEEE 802.15.4-2003;

—

–100

–94

dBm

High-side adjacent channel rejection

IEEE 802.15.4-2003 interferer signal,

wanted IEEE 802.15.4-2003 signal

at –82 dBm

—

Low-side adjacent channel rejection

IEEE 802.15.4-2003 interferer signal,

wanted IEEE 802.15.4-2003 signal

at –82 dBm

—

2nd high-side adjacent channel rejec-

tion

IEEE 802.15.4-2003 interferer signal,

wanted IEEE 802.15.4-2003 signal

at –82 dBm

—

2nd low-side adjacent channel rejection IEEE 802.15.4-2003 interferer signal,

wanted IEEE 802.15.4-2003 signal

at –82 dBm

—

High-side adjacent channel rejection

Filtered IEEE 802.15.4-2003 inter-

ferer signal, wanted IEEE 802.15.4-

2003 signal at –82 dBm

—

Low-side adjacent channel rejection

Filtered IEEE 802.15.4-2003 inter-

ferer signal, wanted IEEE 802.15.4-

2003 signal at –82 dBm

—

2nd high-side adjacent channel



rejection

Filtered IEEE 802.15.4-2003 inter-

ferer signal, wanted IEEE 802.15.4-

2003 signal at –82 dBm

—

2nd low-side adjacent channel rejection

Filtered IEEE 802.15.4-2003 inter-

ferer signal, wanted IEEE 802.15.4-

2003 signal at –82 dBm

—

High-side adjacent channel rejection

CW interferer signal, wanted IEEE

802.15.4-2003 signal at –82 dBm

—

Low-side adjacent channel rejection

CW interferer signal, wanted IEEE

802.15.4-2003 signal at –82 dBm

—
