ADA4350

Data Sheet

Rev. B | Page 12 of 37

Parameter

Test Conditions/Comments1

Min

Typ

Max

Unit

INPUT CHARACTERISTICS

Input Resistance

VIN1 and REF

200

MΩ

Input Capacitance

VIN1 and REF

1.4

Input Common-Mode Voltage Range

3.9

Common-Mode Rejection Ratio

For P1, VCM = ±0.5 V

OUTPUT CHARACTERISTICS

Output Voltage Swing

RL = no load, single-ended

0.15 to 4.85

0.125 to 4.875

RL = 500 Ω, single-ended

0.28 to 4.72

0.24 to 4.76

Output Common-Mode Voltage Range

3.9

Linear Output Current

For P1or M1, VOUT = 1 V p-p, 60 dB SFDR

mA rms

Differential output, VOUT = 1 V p-p, 60 dB SFDR

mA rms

Short-Circuit Current

For P1 or M1, sinking/sourcing

41/63

Capacitive Load Drive

When used differentially at each VOUTx,

30% overshoot, VOUT = 100 mV p-p

When P1/M1 is used, 30% overshoot,

VOUT = 50 mV p-p

POWER SUPPLY

Operating Range

3.3

Positive Power Supply Rejection Ratio

For P1

104

For M1

Negative Power Supply Rejection Ratio

For P1

For M1

P1 and M1 within this table refer to the amplifiers shown in Figure 1.
