A22E

20.4±1.5

BA9S/13

Model indication

Lamp

LED A22-6

@, 12@, 24@

28 max.

BA9S/13

Incandescent Lamp A22-5, 12, 24, H1

4-4

× 38 tapping screw

22.1±

0.3

0.1 dia.

(10

× 36) 0.6 depression

20.5±0.1

Two, 21 dia.

Side lead draw-out hole

Control Box

A22Z-B101Y (1 hole)

16±1 dia.

(Side lead draw-out hole)

Two, mounting holes

Cable Draw-out Hole (Top View)

E-stop Shroud

A22Z-EG1

Sunken

section, 0.2

Switch guard

2.8

20.5

90 dia. 78 dia.

52.2 max.

30 40

75 min.

(Determined by the

height of the Switch

surface in the

lock position.)

22.2 dia.

33 dia.

Panel Cutout Dimensions

Allowable panel thickness: 1 to 3 mm

EMERGENCY OFF

inscription plate (t=1)

Rubber packing (t=0.5)

Locking ring

Mounting panel

2 1

Panel

Switch Unit

A22E-M

2.5

R1.7

22.3

24.2

±0.2

Note 1: The dimensions of the Shroud conform to the

specifications of the SEMATECH Application Guide

for SEMI S2-93.

2: These Shrouds are designed for use only in

semiconductor manufacturing equipment.

Do not use them for any other application.

3: The Shroud is not provided with the Switch.

+0.1

+0.4

+0.5

−1.5
