Electrical Characteristics

i.MX50 Applications Processors for Consumer Products, Rev. 2

Freescale Semiconductor

4.1

Chip-Level Conditions

This section provides the chip-level electrical characteristics for the IC. See Table 6 for a quick reference

to the individual tables and sections.

4.1.1

Absolute Maximum Ratings

CAUTION

Stresses beyond those listed under Table 7 may cause permanent damage to

the device. These are stress ratings only. Functional operation of the device

at these or any other conditions beyond those indicated in Table 11 is not

implied. Exposure to absolute-maximum-rated conditions for extended

periods may affect device reliability.

Table 6. i.MX50 Chip-Level Conditions

For these characteristics, see

Topic appears …

Absolute Maximum Ratings

on page 21

13 x 13 mm MAPBGA Package Thermal Resistance Data

on page 22

13 x 13 mm PoPBGA Package Thermal Resistance Data

on page 23

17 x 17 mm MAPBGA Package Thermal Resistance Data

on page 23

Operating Ranges

on page 24

Operating Frequencies

on page 26

Supply Current

on page 26

Table 7. Absolute Maximum Ratings

Parameter Description

Symbol

Min

Max

Unit

Peripheral core supply voltage

VCC

–0.3

1.5

ARM core supply voltage

VDDGP

–0.3

1.35

Bandgap and 480 MHz PLL supply

VDD3P0

–0.5

3.6

PLL digital supplies

VDD1P2

–0.3

1.35

PLL analog supplies

VDD1P8

–0.3

2.25

Efuse, 24 MHz oscillator, 32 kHz oscillator mux

supply

VDD2P5

–0.5

2.85

Memory array supply

VDDA/VDDAL1

–0.5

1.35

Supply voltage (HVIO)

Supplies denoted as I/O supply

–0.5

3.6

Supply voltage (GPIO, LVIO)

Supplies denoted as I/O supply

–0.5

3.3

Input/output voltage range

Vin/Vout

–0.5

OVDD + 0.31

USB VBUS

VBUS

Transient (t<30ms, duty cycle < 0.05%)

—

6.00

7.00
