ELECTRICAL SPECIFICATIONS

64/111

Issue 1.0 - July 24, 2002

4.5.10 VGA INTERFACE

Table 4-19 lists the AC characteristics of the VGA

interface.

4.5.11 TFT INTERFACE

Table 4-20 lists the AC characteristics of the TFT

interface.

Table 4-19. Graphics Adapter (VGA) AC Timing

Name

Parameter

Min

Max

Unit

DCLK (input) Cycle Time

DCLK (input) High Time

DCLK (input) Low Time

DCLK (input) Rising Time

DCLK (input) Falling Time

DCLK (input) to R,G,B valid

DCLK (input) to HSYNC valid

DCLK (input) to VSYNC valid

DCLK (input) to COL_SEL valid

DCLK (output) Cycle Time

DCLK (output) High Time

DCLK (output) Low Time

DCLK (output) to R,G,B valid

DCLK (output) to HSYNC valid

DCLK (output) to VSYNC valid

DCLK (output) to COL_SEL valid

Table 4-20. TFT Interface Timings

Name

Parameters

Min

Max

Units

DCLK (input) to R[5:0], G[5:0], B[5;0]

DCLK (input) to FPLINE

DCLK (input) to FPFRAME

DCLK (output) to R[5:0], G[5:0], B[5;0]

DCLK (output) to FPLINE

DCLK (output) to FPFRAME
