4.Interface

4.1. LCM PIN Definition

Pin No.

Symbol

Function

Polarity

Note

1

VCC

Power Supply +3.3V(typical)

2

VCC

Power Supply +3.3V(typical)

3

NC

No Conncetion (Reserve for INX test)

4

LR/UD

Reverse Scan Control

H or NC = Normal Mode.

L = Horizonta/ Vertical Reverse Scan.

5

RX0-

LVDS Differential Data Input

Negative

6

RX0+

LVDS Differential Data Input

Positive

7

GND

Ground

8

RX1-

LVDS Differential Data Input

Negative

9

RX1+

LVDS Differential Data Input

Positive

10

NC

No Conncetion (Reserve for INX test)

11

RX2-

LVDS Differential Data Input

Negative

12

RX2+

LVDS Differential Data Input

Positive

13

GND

Ground

14

RXCLK- LVDS Differential Data Input

Negative

15

RXCLK+ LVDS Differential Data Input

Positive

16

GND

Ground

17

RX3-

LVDS Differential Data Input

Negative

18

RX3+

LVDS Differential Data Input

Positive

19

NC

No Conncetion (Reserve for INX test)

20

SEL68

LVDS 6/8 bit select function control,

High → 6bit Input Mode

Low or NC→ 8bit Input Mode

Note (3)

Note (1) Connector Part No.: Cvilux CID520D1HR0-NH or equivalent.

Note (2)

User’s connector Part No.: Entery H204K-D20N-12B or equivalent.

Note (3)

“Low” stands for 0V. “High” stands for 3.3V. “NC” stands for “No Connection”.
