Parameter

Value

Units

Min

Typ

Max

T1

0.5

-

10

ms

T2

0

-

50

ms

T3

0

-

50

ms

T4

500

-

-

ms

T5

200

-

-

ms

T6

200

-

-

ms

T7

5

-

300

ms

T8

10

-

-

ms

T9

10

-

-

ms

T10

20

ms

SCANNING DIRECTION

The following figures show the image see from the front view. The arrow indicates the direction

of scan.

Fig.1 Normal Scan Fig.2 Reverse Scan

Fig. 1 Normal scan ( pin 4, LR/UD = High or NC )

Fig. 2 Reverse scan (pin 4, LR/UD = Low )
