29 / 56 page

www.geehy.com

Page 28

Symbol

Parameter

Condition

Typ

Max

Unit

mode to run

mode

MVR off

Flash

running

HIRC

after

wake-up

53.13

tWU(H)

Wake-up time

from shutdown

to operation

Flash running mode

55.21

Power-on/power-down reset characteristic test

Table 26 Power-on/power-down reset working conditions (TA=25℃)

Symbol

Parameter

Condition

Min

Typ

Max

Unit

tTEMP

Reset release delay

VDD rising

0.58

0.79

0.92

VIT+

Power-on reset threshold

1.79

2.00

2.10

VIT-

Power failure reset

threshold

1.70

1.73

1.76

VHYS(BOR)

BOR hysteresis

100

Power consumption

The current consumption of MCU is affected by many parameters, such as

voltage, temperature, IO status, program location in memory, software

configuration, frequency and so on. The current values given in this section are

measured by executing CRC algorithm, compiling environment Keil V5 and

compiling optimization level L0.

The microcontroller is under the following conditions:

⚫

All I/O pins are in input mode and connected to a static level VDD or VSS

(non-loaded).

⚫

Unless otherwise specified, all peripherals are turned off.

⚫

Unless otherwise specified, typical values are measured at 25℃, 3.3V or

5V.

⚫

Unless otherwise specified, the maximum values are measured at 105℃

and 5.5V power supply.

Table 27 Typical operating mode power consumption

Symbol

Parameter

Condition

Voltage(TA=25℃)

Unit

3.3V

IDD

HXT=24MHz，FCPU=24MHz

2.5

3.1
