R3111x
16
 R3111E (TO-92) is the discontinued product as of April, 2017.
600
500
400
300
200
100
0
0
25
50
75
100
125
150
Ambient Temperature (
C)
85
SON1612-6 Power Dissipation
On Board
 Power Dissipation (SON1612-6)
Power Dissipation (PD) depends on conditions of mounting on board.
This specification is based on the measurement at the condition below:
Measurement Conditions
Standard Land Pattern
Environment
Mounting on Board (Wind velocity 0m/s)
Board Material
Glass cloth epoxy plastic (Double layers)
Board Dimensions
40mm
 40mm  1.6mm
Copper Ratio
Top side: Approx. 50%, Back side: Approx. 50%
Through - hole
 0.5mm  24pcs
Measurement Results
(Ta=25
C, Tjmax=125C)
Standard Land Pattern
Power Dissipation
500mW
Thermal Resistance
ja = (125-25C)/ 0.5W = 200C/W
40
39
27
Measurement Board Pattern
IC Mount Area Unit : mm
