R3111x

4

 R3111E (TO-92) is the discontinued product as of April, 2017.

PIN CONFIGURATIONS



TO-92



SOT-89



SOT-23-3



SOT-23-5

3

12

(mark side)

3

12

(mark side)

12

3

(mark side)

12

3

4

5

(mark side)



SC-82AB



SC-88A



SON1612-6

4

3

1

2

(mark side)

5

4

1

3

2

(mark side)

12

3

65

4

(mark side)

PIN DESCRIPTIONS



TO-92



SOT-89



SOT-23-3



SOT-23-5

Pin No.

Symbol

Pin No.

Symbol

Pin No.

Symbol

Pin No.

Symbol

1

VDD

1

OUT

1

OUT

1

OUT

2

GND

2

VDD

2

GND

2

VDD

3

OUT

3

GND

3

VDD

3

GND

4

NC

5

NC



SC-82AB



SC-88A



SON1612-6

Pin No.

Symbol

Pin No.

Symbol

Pin No.

Symbol

1

OUT

1

OUT

1

OUT

2

VDD

2*

NC

2

VDD

3

NC

3

VDD

3

GND

4

GND

4

NC

4

NC

5

GND

5

VDD

6

NC

* Pin No. 2 is connected to the bottom of the IC. It is recommended that the pin be connected to the VDD pin on the board, or

otherwise be left floating so that there is no contact with other potentials.
