AD8190

Rev. 0 | Page 4 of 24

Parameter

Conditions/Comments

Min

Typ

Max

Unit

SERIAL CONTROL INTERFACE5

Input High Voltage, VIH

Input Low Voltage, VIL

0.8

Output High Voltage, VOH

2.4

Output Low Voltage, VOL

0.4

1 Differential interpair skew is measured between the TMDS pairs of a single link.

2 AD8190 output meets the transmitter eye diagram as defined in the DVI Standard Revision 1.0 and the HDMI Standard Revision 1.2a.

3 Cable output meets the receiver eye diagram mask as defined in the DVI Standard Revision 1.0 and the HDMI Standard Revision 1.2a.

4 Typical value assumes only the selected HDMI/DVI link is active with nominal signal swings and that the unselected HDMI/DVI link is deactivated. Minimum and

maximum limits are measured at the respective extremes of input termination resistance and input voltage swing.

5 The AD8190 is an I2C slave and its serial control interface is based on the 3.3 V I2C bus specification.
