Command(7)

50h

C/D/H(6)

1

LBA

1

Drive

Head(LBA 27-24)

Cyl High(5)

Cylinder High (LBA 23-16)

Cyl Low(4)

Cylinder Low (LBA 15-8)

Sec Num(3)

X (LBA 7-0 )

Sec Cnt(2)

Count (LBA mode only)

Feature(1)

X

Format Track

This command writes the desired head and cylinder of the selected drive with a vendor unique data pattern

(typically FFh or 00h).

To remain host backward compatible, the CompactFlash Storage Card expects a sector buffer of data from the

host to follow the command with the same protocol as the Write Sector(s) command although the information in the

buffer is not used by the CompactFlash Storage Card.

If LBA=1 then the number of sectors to format is taken from the SecCnt register (0=256). The use of this command

is not recommended.

Identify Drive - ECh

Bit->

7

6

5

4

3

2

1

0

Command(7)

ECh

C/D/H(6)

X

X

X

Drive

X

Cyl High(5)

X

Cyl Low(4)

X

Sec Num(3)

X

Sec Cnt(2)

X

Feature(1)

X

Identify Drive

The Identify Drive command enables the host to receive parameter information from the

CompactFlash Storage Card. This command has the same protocol as the Read Sector(s)

command. The parameter words in the buffer have the arrangement and meanings defined in

Table . All reserved bits or words are zero. Table 40 is the definition for each field in the

Identify Drive Information.

Table: Identify Drive Information

Word

Address

Default

Value

Total

Bytes

Data Field Type Information

0

848Ah

2

General configuration – signature for the CompactFlash Storage Card

1

xxxxh

2

Default number of cylinders

2

0000h

2

Reserved

3

00xxh

2

Default number of heads

4

xxxxh

2

Number of unformatted bytes per track

5

xxxxh

2

Number of unformatted bytes per sector

6

xxxxh

2

Default number of sectors per track

7-8

xxxxh

4

Number of sectors per card (Word 7 = MSW , word 8 = LSW)
