HANBit

HFDOM40KRxxx

URL:www.hbe.co.kr

1 / 1

HANBit Electronics Co., Ltd.

Rev. 1.2 (Decemver. 2003)

1. PRODUCT OVERVIEW

GENERAL DESCRIPTION

The HFDOM40KRxxx series 40Pin Flash Disk Module is a flash technology based with True IDE interface flash memory

card. It is constructed with flash disk controller chip and NAND-type (Samsung) flash memory device. The HFDOM40KR-

xxx series operates in both 3.3-Volt and 5.0-Volt power supplies. It comes in capacity of 16, 32, 64, 128, 192, 256, 512 MB

and up to 1GB MB formatted 40Pin type .

By optimizing flash memory management, the life of this HFDOM40KRxxx series can be extended to its maximum level.

Because the ECC function is included, the correctness of data transfer between the HFDOM40KRxxx series and a True

IDE compatible interface device can be guaranteed.

The HFDOM40KRxxx series is fully compatible with applications such as CPU card / board, set top box, industry /

military PC / Notebook, security equipment, measuring instrument and embedded systems.

FEATURES

-

ATA / True IDE compatible host interface

-

ATA command set compatible

-

Automatic sensing of PC Card ATA or true IDE host interface.

-

Very high performance, very low power consumption

-

Automatic error correction

-

Auto Standby to save power consumption.

-

Supports power down commands and sleep modes.

-

Support for 8 or 16 bit host transfers

-

3.3V/5.0V operation voltage

-

Host Interface bus width : 8/16 bit Access

-

Flash Interface bus width : 8 bit Access

-

Capacity : Min. 16MB ~ Max. 1GMB

PRODUCT SPECIFICATIONS

Capacities :

16, 32, 48, 64, 96, 128, 192, 256, 512 and up to 1GB (formatted)

System Compatibility :

Please refer to the compatibility list of index.

Performance :

Host Data Transfer Rates :

up to 16.6 MB/sec, PIO mode 4; 16.6MB/sec, Multi-word

DMA mode 2; 33MB/sec

40Pin Flash Disk Module Min.8MB ~ Max.1GB, True IDE Interface

Mode, 3.3V / 5.0V Operating

Part No. HFDOM40KRxxx
