Bit 7: this bit is in High Imoedence..

Implementation Note:

Conflicts may occur on the host data bus when this bit is provided by a Floppy Disk Controller

operating at the same addresses as the CompactFlash Storage Card. Following are some

possible solutions to this problem for the PCMCIA implementation:

1) Locate the CompactFlash Storage Card at a non-conflicting address, i.e. Secondary

address (377) or in an independently decoded Address Space when a Floppy Disk Controller

is located at the Primary addresses.

2) Do not install a Floppy and a CompactFlash Storage Card in the system at the same time.

3) Implement a socket adapter, which can be programmed to (conditionally) tri-state D7 of I/0

address 3F7h/377h when a Compact Flash Storage Card is installed and conversely to tri-state

D6-D0 of I/O address 3F7h/377h when a floppy controller is installed.

4) Do not use the CompactFlash Storage Card’s Drive Address register. This may be

accomplished by either a) If possible, program the host adapter to enable only I/O addresses

1F0h-1F7h, 3F6h (or 170h-177h, 176h) to the CompactFlash Storage Card or b) if provided

use an additional Primary / Secondary configuration in the CompactFlash Storage Card

which does not respond to accesses to I/O locations 3F7h and 377h. With either of these

implementations, the host software must not attempt to use information in the Drive Address

Register.

Bit 6 (-WTG): this bit is 0 when a write operation is in progress, otherwise, it is 1.

Bit 5 (-HS3): this bit is the negation of bit 3 in the Drive/Head register.

Bit 4 (-HS2): this bit is the negation of bit 2 in the Drive/Head register.

Bit 3 (-HS1): this bit is the negation of bit 1 in the Drive/Head register.

Bit 2 (-HS0): this bit is the negation of bit 0 in the Drive/Head register.

Bit 1 (-nDS1): this bit is 0 when drive 1 is active and selected.

Bit 0 (-nDS0): this bit is 0 when the drive 0 is active and selected.

4. ATA COMMAND

CF-ATA Command Set

Table summarizes the CF-ATA command set with the paragraphs that follow describing the

individual commands and the task file for each.

Table:CF-ATA Command Set

Class

COMMAND

Code

FR

SC

SN

CY

DH

LBA

1

Check Power Mode

E5h or 98h

-

-

-

-

D

-

1

Execute Drive Diagnostic 90h

-

-

-

-

D

-

2

Format Track

50h

-

Y

-

Y

Y

Y

1

Identify Drive

ECh

-

-

-

-

D

-

1

Idle

E3h or 97h

-

Y

-

-

D

-

1

Idel Immediate

E1h or 95h

-

-

-

-

D

-

1

Initialize Drive Parameters 91h

-

Y

-

-

Y

-

1

Read Buffer

E4h

-

-

-

-

D

-

1

Read Long Sector

22h or 23h

-

-

Y

Y

Y

Y

1

Read Multiple

C4h

-

Y

Y

Y

Y

Y

1

Read Sector(s)

20h or 21h

-

Y

Y

Y

Y

Y

1

Read Verify Sector(s)

40h or 41h

-

Y

Y

Y

Y

Y

1

Recalibrate

1Xh

-

-

-

-

D

-

1

Request Sence

03h

-

-

-

-

D

-

1

Seek

7Xh

-

-

Y

Y

Y

Y

1

Set Features

EFh

Y

-

-

-

D

-
