Microcontroller Interface

Used in a typical system,

CC1070 will

interface

microcontroller.

This

microcontroller must be able to:

• Program

CC1070 into different modes

via the 4-wire serial configuration

interface (PDI, PDO, PCLK and PSEL)

• Interface to the synchronous data

signal interface (DI and DCLK)

• Optionally, the microcontroller can do

data encoding

• Optionally, the microcontroller can

monitor the LOCK pin for frequency

lock status or other status information.

Configuration interface

The microcontroller interface is shown in

Figure 5. The microcontroller uses 3 or 4

I/O pins for the configuration interface

(PDI, PDO, PCLK and PSEL). PDO

should be connected to a microcontroller

input. PDI, PCLK and PSEL must be

microcontroller outputs. One I/O pin can

be saved if PDI and PDO are connected

together and a bi-directional pin is used at

the microcontroller.

The microcontroller pins connected to PDI,

PDO and PCLK can be used for other

purposes when the configuration interface

is not used. PDI, PDO and PCLK are high

impedance inputs as long as PSEL is not

activated (active low).

PSEL has an internal pull-up resistor and

should be left open (tri-stated by the

microcontroller) or set to a high level

during power down mode in order to

prevent a trickle current flowing in the pull-

up.

Signal interface

The DI pin is used for data to be

transmitted. DCLK providing the data

timing

should

connected

microcontroller input.

PLL lock signal

Optionally, one microcontroller pin can be

used to monitor the LOCK signal. This

signal is at low logic level when the PLL is

in lock. It can also be used to monitor

other internal test signals.

CC1070

PDI

PCLK

PSEL

LOCK

Micro-

controller

DCLK

(Optional)

PDO

(Optional)

CC1070

PDI

PCLK

PSEL

LOCK

Micro-

controller

DCLK

(Optional)

PDO

(Optional)

Figure 5. Microcontroller interface
