ADRF6604ACPZ-R7 bảng dữ liệu(PDF) 15 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADRF6604ACPZ-R7 bảng dữ liệu(HTML) 15 Page - Analog Devices |
|
|
15 / 32 page  Data Sheet ADRF6604 Rev. B | Page 15 of 32 SPURIOUS PERFORMANCE (N × fRF) − (M × fLO) spur measurements were made using the standard evaluation board (see the Evaluation Board section). Mixer spurious products were measured in decibels relative to the carrier (dBc) from the IF output power level. All spurious components greater than −125 dBc are shown. LO = 2500 MHz, RF = 2360 MHz (horizontal axis is M, vertical axis is N), and RFIN power = 0 dBm. M N 0 1 2 3 4 0 -115.19 −43.0184 −33.3455 1 −23.6708 0.0 −67.1671 −47.1921 2 −63.4281 −65.1191 −61.1065 −79.8957 −80.0324 3 −83.6746 −86.8944 −58.5001 −105.514 4 −108.708 −104.041 −108.518 5 −110.825 −113.19 6 −108.548 7 LO = 2700 MHz, RF = 2560 MHz (horizontal axis is M, vertical axis is N), and RFIN power = 0 dBm. M N 0 1 2 3 4 0 −114.804 −42.7987 −31.9174 1 −22.6289 0.0 −65.0063 −48.5279 2 −61.2522 −66.5602 −57.5224 −77.0905 −76.8305 3 −84.4436 −82.5056 −56.9437 −98.8811 4 −108.087 −98.5103 −99.2295 5 −110.572 −113.601 6 −109.829 7 LO = 2900 MHz, RF = 2760 MHz (horizontal axis is M, vertical axis is N), and RFIN power = 0 dBm. M N 0 1 2 3 4 0 −114.956 −44.0336 −31.2423 1 −22.092 0.0 −62.6978 −48.9358 2 −60.2824 −69.8043 −56.7826 −73.218 3 −85.957 −80.7407 −56.7503 −105.061 4 −108.949 −100.938 −100.159 5 −110.193 −111.146 6 −111.428 7 |
|
