39 / 62 page

Data Sheet

ADM1266

Rev. A | Page 39 of 62

MFR_ID

The MFR_ID command either sets or reads the manufacturer ID. MFR_ID is typically set only once, at the time of manufacture. The

maximum length of the ID is 32 bytes.

Table 36. Register 0x99—MFR_ID (for Block WR)

Byte

Byte Name

R/W

Description

Parameter length

Block W

Parameter data length, fixed to 1.

ID length

Block W

The length of the manufacturer ID data to read back. Maximum = 32 bytes.

Data length

Block R

The length of the manufacturer ID data that the ADM1266 returns.

[64:1]

Data

Block R

Manufacturer ID data.

Table 37. Register 0x99—MFR_ID (for Block W)

Byte

Byte Name

R/W

Description

Data length

Block W

The length of the manufacturer ID data to write. Maximum = 32 bytes.

[64:1]

Data

Block W

Manufacturer ID data.

MFR_MODEL

The MFR_MODEL command either sets or reads the manufacturer model number. MFR_MODEL is typically set only once, at the time

of manufacture. The maximum length of the model number is 32 bytes.

Table 38. Register 0x9A—MFR_MODEL (for Block WR)

Byte

Byte Name

R/W

Description

Parameter length

Block W

Parameter data length, fixed to 1.

ID length

Block W

The length in bytes of manufacturer model number to read back. Maximum = 32 bytes.

Data length

Block R

The length of the manufacturer model number that the ADM1266 returns.

[64:1]

Data

Block R

Manufacturer model data.

Table 39. Register 0x9A—MFR_MODEL (for Block W)

Byte

Byte Name

R/W

Description

Data length

Block W

The length in bytes of manufacturer model number to write. Maximum = 32 bytes.

[64:1]

Data

Block W

Manufacturer model data.

MFR_REVISION

The MFR_REVISION command either sets or reads the manufacturer revision number. MFR_REVISION is typically set only once, at the

time of manufacture. The maximum length of the revision number is 8 bytes.

Table 40. Register 0x9B—MFR_REVISION (for Block WR)

Byte

Byte Name

R/W

Description

Parameter length

Block W

Parameter data length, fixed to 1.

ID length

Block W

The length of manufacturer revision number to read back. Maximum = 8 bytes.

Data length

Block R

The length of the manufacturer revision number that the ADM1266 returns

[64:1]

Data

Block R

Manufacturer revision data

Table 41. Register 0x9B—MFR_REVISION (for Block W)

Byte

Byte Name

R/W

Description

Data length

Block W

The length of manufacturer revision number to write. Maximum = 8 bytes.

[64:1]

Data

Block W

Manufacturer’s revision data
