Data Sheet

HMC974LC3C

Rev. E | Page 5 of 12

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

−0.5 V to +4 V

−0.5 V to +4 V

−0.5 V to +3 V

−3.3 V to +0.5 V

Input Voltage

−2 V to +2 V

Differential Input Voltage

−2 V to +2 V

Output Current

40 mA

Junction Temperature

125°C

Continuous Power Dissipation (T = 85°C;

Derate 20.4 mW/°C Above 85°C)

0.816 W

49°C/W

Moisture Sensitivity Level 1 (MSL1) and

Moisture Sensitivity Level 3 (MSL3)

260°C

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Electrostatic Discharge (ESD) Sensitivity

Human Body Model

Class 1B

1

See the Ordering Guide section.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
