QPD1025L

1500 W, 65 V, 1.0

– 1.1 GHz, GaN RF Input-Matched Transistor

Datasheet Rev. B

│ Subject to change without notice

- 13 of 18 -

www.qorvo.com

1-

The QPD1025L

will be marked with the “QPD1025L” designator and a lot code marked below the part designator. The “YY”

represents the last two digits of the calendar year the part was manufactured, the “WW” is the work week of the assembly lot

st

art, the “MXXX” is the production lot number, and the “ZZZ” is an auto-generated serial number.

Pin

Symbol

Description

1, 2

Gate

3, 4

Drain

5

Source

Source / Ground / Backside of part
