AD8233

Data Sheet

Rev. 0 | Page 6 of 29

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

3.6 V

Output Short-Circuit Current Duration

Indefinite

Maximum Voltage, Any Terminal1

+VS + 0.3 V

Minimum Voltage, Any Terminal1

−0.3 V

Storage Temperature Range

−65°C to +125°C

Operating Temperature Range

−40°C to +85°C

Maximum Junction Temperature

140°C

ESD Rating

HBM

8 kV

Charged Device Model (FICDM)

1 kV

1 This level or the maximum specified supply voltage, whichever is the lesser,

indicates the superior voltage limit for any terminal. If input voltages beyond

the specified minimum or maximum voltages are expected, place resistors in

series with the inputs to limit the current to less than 5 mA.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to printed circuit board

(PCB) design and operating environment. Careful attention to

PCB thermal design is required.

Table 4. Thermal Resistance

Package

Type

PCB

Power (W)

θJA (°C/W)

θJC

(°C/W)

0 ms

1 ms

2 ms

CP-20-13

1S0P1

0.25

108.5

89.0

82.3

0.6

1.25

101.1

87.3

0.6

2S2P2

0.25

47.9

43.4

42.1

0.7

1.25

46.8

43.3

42.1

0.7

1 Simulated thermal numbers per JESD51-9: 1-layer PCB (1S0P), low effective

thermal conductivity test board.

2 4-layer PCB (2S2P), high effective thermal conductivity test board.

ESD CAUTION
