AD8421

Data Sheet

Rev. 0 | Page 18 of 28

50mV/DIV

GAIN = 10

1µs/DIV

Figure 52. Small Signal Pulse Response (G = 10), RL = 600 Ω, CL = 100 pF

20mV/DIV

GAIN = 100

1µs/DIV

Figure 53. Small Signal Pulse Response (G = 100), RL = 600 Ω, CL = 100 pF

20mV/DIV

GAIN = 1000

2µs/DIV

Figure 54. Small Signal Pulse Response (G = 1000), RL = 600 Ω, CL = 100 pF

G = 1

NO LOAD

20pF 50pF

100pF

50mV/DIV

1µs/DIV

Figure 55. Small Signal Response with Various Capacitive Loads (G = 1),

RL = Infinity

–40

–150

10k

100

FREQUENCY (Hz)

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

RL ≥ 600Ω

VOUT = 10V p-p

Figure 56. Second Harmonic Distortion vs. Frequency (G = 1)

–40

–150

10k

100

FREQUENCY (Hz)

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

NO LOAD

RL = 2kΩ

RL = 600Ω

VOUT = 10V p-p

Figure 57. Third Harmonic Distortion vs. Frequency (G = 1)
