Absolute Maximum Ratings

ADE3700

84/89

Electrical Specifications

3.1

Absolute Maximum Ratings

3.2

Power Consumption Matrices

Measured at nominal voltage supplies

Measured at +10% voltage supplies

Measured at nominal voltage supplies

Measured at +10% voltage supplies

Symbol

Parameter

Min.

Typ.

Max.

Unit

AVDD18

DVDD18

XVDD18

LVDD18

Supply voltage

1.95

AVDD33

DVDD33

Supply voltage

3.6

VIN

Max voltage on 5 volt tolerant input pins

6.1

TSTG

Storage temperature

-40

+150

°C

Table 36: ADE3700x

Symbol

Parameter

Min

Typ*

Max**

Unit

Supply Current (Analog Input, XGA@75Hz, 78.75MHz)

IAVDD18

1.8V analog supply (IAVDD18)

195

203

IDVDD18

1.8V digital supply (IDVDD18)

228

257

IAVDD33

3.3V analog supply (IAVDD33)

102

105

IDVDD33

3.3V digital supply (IDVDD33)

4451mA

PTOTANA

Total Power Consumption (Analog Input, XGA@75Hz, 78.75MHz)

1.25

1.48

Table 37: ADE3700xs

Symbol

Parameter

Min

Typ*

Max**

Unit

Supply Current (Analog Input, XGA@75Hz, 135MHz)

IAVDD18

1.8V analog supply (IAVDD18)

200

207

IDVDD18

1.8V digital supply (IDVDD18)

351

401

IAVDD33

3.3V analog supply (IAVDD33)

104

108

IDVDD33

3.3V digital supply (IDVDD33)

6880mA

PTOTANA

Total Power Consumption (Analog Input, XGA@75Hz, 135MHz)

1.56

1.89
