(9/9)

INDUC

T

O

RS

20160411 / inductor_commercial_power_vls252010cx_en.fm

Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

VLS252010CX Type

PACKAGING STYLE

REEL DIMENSIONS

* These values are typical values.

TAPE DIMENSIONS

Type

A

W1

W2

N

E

VLS252010CX

ø180

9

13

ø60

0.5

ø13.0

±0.5

ø21.0

±0.8

2.0

±0.5

A

(1.0)

Dimensions in mm

E

W2

W1

P0

P2

øD0

P1

A

t

K

Dimensions in mm

Type

A

B

øD0

E

F

P0

P1

P2

W

K

t

VLS252010CX

2.3

2.8

1.5+0.1/-0

1.75±0.1

3.5±0.05

4.0±0.1

4.0±0.1

2.0±0.05

8.0±0.2

1.15

0.25
