Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

Inductors for Power Circuits

Wound Ferrite

FEATURES

Magnetic shield type wound inductor for power circuits using a ferrite magnetic material.

High magnetic shield construction and compatible with high-density mounting.

Larger current and lower Rdc were achieved by optimizing the ferrite core figure.

APPLICATION

Smart phones, tablet terminals, HDDs, SSDs, DVCs, DSCs, mobile display panels, portable game devices, compact power supply

modules, other

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

Overview of VLS252010CX Type

VLS

252010

C

X

-

R47

M

Series name

L×W×H Dimensions

Internal code 1

Internal code 2

Inductance

Inductance

tolerance

(mm)

(μH)

252010

2.5×2.0×1.0

R47

0.47

M

±20%

2R2

2.2

100

10

Type

Temperature range

Package quantity

Individual weight

Operating

（°C）

Storage

（°C）

(pieces/reel)

（mg）

VLS252010CX

–40 to +105

–40 to +105

2000

24

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
