EM359x

Rev 1.0

PB6

I/O

High

current

Digital I/O

ADC1

Analog

ADC Input 1

Enable analog function with GPIO_PBCFGH[11:8]

IRQB

External interrupt source B

TIM1C1

Timer 1 channel 1 output

Enable timer output in TIM1_CCER

Select alternate output function with GPIO_PBCFGH[11:8]

TIM1C1

Timer 1 channel 1 input

Cannot be remapped

PB5

I/O

Digital I/O

ADC0

Analog

ADC Input 0

Enable analog function with GPIO_PBCFGH[7:4]

TIM2CLK

Timer 2 external clock input

TIM1MSK

Timer 1 external clock mask input

VDD_CORE

Power

1.25 V digital core supply decoupling

VDD_PRE

Power

1.8 V prescaler supply

VDD_SYNTH

Power

1.8 V synthesizer supply

OSCB

I/O

24 MHz crystal oscillator or left open when using external clock input on

OSCA

GND

Ground

Ground supply pad in the bottom center of the package forms Pin 57. See

the various Ember EM359x Reference Design documentation for PCB con-

siderations.

Table 6.1. EM359x Pin Descriptions (Continued)

Pin #

Signal

Direction

Description

Note:

IRQC and IRQD external interrupts can be mapped to any digital I/O pin using the GPIO_IRQCSEL and

GPIO_IRQDSEL registers.
