27 / 83 page  UCD3138A www.ti.com SLUSC66B – MARCH 2015 – REVISED MAY 2015 6.3.1 CPU Memory Map and Interrupts When the device comes out of power-on-reset, the data memories are mapped to the processor as follows: 6.3.1.1 Memory Map (After Reset Operation) Address Size Module 0x0000_0000 – 0x0000_FFFF 16 X 4K Boot ROM In 16 repeated blocks of 4K each 0x0001_0000 – 0x0001_7FFF 32K Program flash 0x0001_8800 – 0x0001_8FFF 2K Data flash 0x0001_9000 – 0x0001_9FFF 4K Data RAM 6.3.1.2 Memory Map (Normal Operation) Just before the boot ROM program gives control to FLASH program, the ROM configures the memory as follows: Address Size Module 0x0000_0000 – 0x0000_7FFF 32K Program flash 0x0001_0000 – 0x0001_AFFF 4K Boot ROM 0x0001_8800 – 0x0001_8FFF 2K Data flash 0x0001_9000 – 0x0001_9FFF 4K Data RAM 6.3.1.3 Memory Map (System and Peripherals Blocks) Address Size Module 0x0002_0000 - 0x0002_00FF 256 Loop Mux 0x0003_0000 - 0x0003_00FF 256 Fault Mux 0x0004_0000 - 0x0004_00FF 256 ADC 0x0005_0000 - 0x0005_00FF 256 DPWM 3 0x0006_0000 - 0x0006_00FF 256 Filter 2 0x0007_0000 - 0x0007_00FF 256 DPWM 2 0x0008_0000 - 0x0008_00FF 256 Front End/Ramp I/F 2 0x0009_0000 - 0x0009_00FF 256 Filter 1 0x000A_0000 - 0x000A_00FF 256 DPWM 1 0x000B_0000 – 0x000B_00FF 256 Front End/Ramp I/F 1 0x000C_0000 - 0x000C_00FF 256 Filter 0 0x000D_0000 - 0x000D_00FF 256 DPWM 0 0x000E_0000 - 0x000E_00FF 256 Front End/Ramp I/F 0 0xFFF7_EC00 - 0xFFF7_ECFF 256 UART 0 0xFFF7_ED00 - 0xFFF7_EDFF 256 UART 1 0xFFF7_F000 - 0xFFF7_F0FF 256 Miscellaneous Analog Control 0xFFF7_F600 - 0xFFF7_F6FF 256 PMBus Interface 0xFFF7_FA00 - 0xFFF7_FAFF 256 GIO 0xFFF7_FD00 - 0xFFF7_FDFF 256 Timer 0xFFFF_FD00 - 0xFFFF_FDFF 256 MMC 0xFFFF_FE00 - 0xFFFF_FEFF 256 DEC 0xFFFF_FF20 - 0xFFFF_FF37 23 CIM 0xFFFF_FF40 - 0xFFFF_FF50 16 PSA 0xFFFF_FFD0 - 0xFFFF_FFEC 28 SYS Copyright © 2015, Texas Instruments Incorporated Detailed Description 27 Submit Documentation Feedback Product Folder Links: UCD3138A |
|
