Mitsubishi microcomputers
M16C / 62A Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Processor Mode
23
Single-chip mode
SFR area
Internal
RAM area
Inhibited
Internal
ROM area
Microprocessor mode
SFR area
Internal
RAM area
External
area
Internally
reserved area
0000016
0040016
XXXXX16
YYYYY16
FFFFF16
D000016
External area : Accessing this area allows the user to
access a device connected externally
to the microcomputer.
0400016
Memory expansion mode
SFR area
Internal
RAM area
External
area
Internal
ROM area
Internally
reserved area
Internally
reserved area
Note : These memory maps show an instance in which PM13 is set to 0; but in the case of M30624MGA/FGA,
they show an instance in which PM13 is set to 1.
M30622M4A
00FFF16
F800016
C000016
053FF16
M30624MGA/FGA
M30620M8A
02BFF16
F000016
E800016
017FF16
M30622MAA
E000016
017FF16
M30622MCA
M30620MAA
E800016
02BFF16
M30622M8A
F000016
013FF16
Address XXXXX16
Type No.
Address YYYYY16
M30620MCA/FCA
E000016
02BFF16
Figure 1.7.2. Memory maps in each processor mode (without memory area expansion, normal mode)
