Mitsubishi microcomputers

M16C / 62A Group

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

Timer

Figure 1.14.2. Timer B block diagram

• Event counter mode

• Timer mode

• Pulse width measuring mode

• Timer mode

• Pulse width measuring mode

• Timer mode

• Pulse width measuring mode

TB0IN

TB1IN

TB2IN

Timer B0

Timer B1

Timer B2

f1 f8 f32 fC32

Timer B0 interrupt

Noise

filter

Noise

filter

Noise

filter

1/32

fC32

1/8

1/4

f32

XIN

XCIN

Clock prescaler reset flag (bit 7

at address 038116) set to “1”

Reset

Clock prescaler

Timer A

• Event counter mode

• Timer mode

• Pulse width measuring mode

• Timer mode

• Pulse width measuring mode

• Timer mode

• Pulse width measuring mode

TB3IN

TB4IN

TB5IN

Timer B3

Timer B4

Timer B5

Timer B3 interrupt

Noise

filter

Noise

filter

Noise

filter

Timer B1 interrupt

Timer B2 interrupt

Timer B4 interrupt

Timer B5 interrupt

Note 1: The TB5IN pin (P71) is shared with RxD2 and the TA0IN pin, so be careful.
