RM0345
CAN interface
Doc ID 024080 Rev 3
21/38
The cut trace options J6, J17, J18 and J19 has been put in the design of this board to select
the supply of the CAN transceiver between 5 V and 3.3 V. By this option is possible to
replace the ST L9616 High-Speed Transceiver mounted on board by default, with a different
transceiver that operates at 3.3 V.
Note:
Refer to Section Appendix D: Options placement for layout options placement.
Table 9.
J6, J17 and J7 FlexCAN interface selection
J6 (or J17 if 3.3V)
J7
FlexCAN interface
closed
open
low speed operation (default)
(CAN baud rate up to 250kBaud)
open
closed
high speed operation
(CAN baud rate from 250kBaud to 1000kBaud)
Table 10.
CAN transceiver operating voltage selection
CAN Transceiver
J6
J17
J18
J19
5V - ST L9616 High-Speed
Transceiver
Adjustable
Slope Control
open
open
close
3.3V - CAN transceiver
open
Adjustable
Slope Control
close
open
