47.4 Pushbuttons and Indicating Lights

M22 Modular Pushbuttons

Surface Mounting Enclosures

Flush Mounting Plates, Aluminum

Shrouds, Plastic

Selector Switch Accessories

Emergency Stop Operator Accessories

Blanking Plugs

Notes

Plunger needed to actuate center-mounted contact blocks. Used for non-illuminated

3-position selector switches only.

Enables a keyed selector switch to be set to user-selected key withdraw position.

Discount Symbol: 1CD1.

Description

Catalog

Number

Price

U.S. $

Yellow Top, Black Base for

Emergency-Stop Operators

M22-IY1-PG

63.50

1 Element Enclosure

M22-I1-PG

59.00

2 Element Enclosure

M22-I2-PG

64.00

3 Element Enclosure

M22-I3-PG

70.00

4 Element Enclosure

M22-I4-PG

78.00

6 Element Enclosure

M22-I6-PG

92.50

M20 Connecting Screw

M22-XI

8.00

M20 Cord Grip

V-M20

8.00

Finish

Rating

Catalog

Number

Price

U.S. $

1 Hole

Yellow Paint for

Emergency-Stop

Operators

—

M22-EY1

39.00

Gray Anodized

IP65

M22-E1

35.00

2 Holes

Gray Anodized

IP65

M22-E2

46.00

3 Holes

Gray Anodized

IP65

M22-E3

51.00

4 Holes

Gray Anodized

IP65

M22-E4

66.00

5 Holes

Gray Anodized

IP65

M22-E5

78.00

6 Holes

Anodized

IP40

M22-E6

94.00

Description

Rating

Catalog

Number

Price

U.S. $

1-Element

IP55

M22-H1

12.00

2-Element

IP55

M22-H2

25.00

3-Element

IP55

M22-H3

39.00

4-Element

IP40

M22-H4

53.00

5-Element

IP40

M22-H5

65.00

6-Element

IP40

M22-H6

79.00

Mounting Plate

—

M22-XE5

13.00

Plaster Keys for

Flush Mounting

—

M22-UPE

12.00

M22-IY1-PG

M22-EY1

M22-H1

Description

Catalog

Number

Price

U.S. $

Plunger Bridge

M22-XW

4.00

Key Cover

M22-XWS

10.00

Key Withdraw Adapter

M22-XC-R

4.00

Coding Adapter

M22-XC-Y

4.00

Description

Catalog

Number

Price

U.S. $

Guard Ring

M22-XGWK

11.25

Yellow Guard Ring

M22-XGPV

16.25

Gray Guard Ring

M22G-XGPV

16.25

Sealing Shroud

M22-PL-PV

22.00

Color

Catalog

Number

Price

U.S. $

Gray

M22-B

3.70

Black

M22S-B

3.70

M22-XC-Y

M22-XWS

M22-XC-R

M22-XW

M22-XGWK

M22-XGPV

M22G-XGPV

M22-B
