SMD Type CERAFIL

r Standard Land Pattern Dimensions

(in mm)

2.0

2.475

6.95

0.925

2.0

2.0

1.1

c SFPKA Series

(in mm)

1.2

0.7

0.7

1.4

1.2

c CFUKG/CFUKF Series

(in mm)

1.2

3.0

3.0

5.5

4-R3.0

11.5

1.8

c CFWKA Series

Input

Ground

No connect

Output

(1):

(2)(5):

(3)(4):

(6):

(in mm)

It shows solder resist land pattern.

0.8

0.6

0.8

0.6

0.8

0.1

0.1

(6)

(5)

(4)

(1)

(2)

(3)

c SFECF10M7 Series

(in mm)

It shows solder resist land pattern.

(1): Input

(2): Output

(3): No Connect

(4): Ground

0.5

1.4

0.1

0.1

1.05

(3)

(4)

(2)

(1)

c SFSCE10M Series

P05E.pdf

Nov.24,2011

31

• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
