MHz SMD Type CERAFIL

r Notice

o Handling

1. Accurate test circuit values are required to measure

electrical characteristics. Miscorrelation may be caused if

there is any deviation, especially stray capacitance, from

the test circuit in the specification.

2. For safety purposes, connect the output of filters to the IF

amplifier through a D.C. blocking capacitor. Avoid

applying a direct current to the output of ceramic filters.

Continued from the preceding page.

Do not clean or wash the component as it is not

hermetically sealed.

2. Wash

In case of overcoating the component, conditions such as

material of resin, cure temperature, and so on should be

evaluated well.

3. Coating

o Storage and Operating Conditions

1. Product Storage Condition

Please store the products in a room where the

temperature/humidity is stable, and avoid places where

there are large temperature changes. Please store the

products under the following conditions:

Temperature: -10 to + 40°C

Humidity: 15 to 85% R.H.

2. Expiration Date on Storage

Expiration date (shelf life) of the products is six months

after delivery under the conditions of a sealed and

unopened package. Please use the products within six

months after delivery. If you store the products for a long

time (more than six months), use carefully because

solderability may be degraded due to storage under poor

conditions.

Please confirm solderability and characteristics for the

products regularly.

3. Notice on Product Storage

(1) Please do not store the products in a chemical

atmosphere (Acids, Alkali, Bases, Organic gas,

Sulfides and so on), because the characteristics may

be reduced in quality and may be degraded in

solderability due to storage in a chemical atmosphere.

(2) Please do not put the products directly on the floor

without anything under them to avoid damp places

and/or dusty places.

(3) Please do not store the products in places such as a

damp heated place or any place exposed to direct

sunlight or excessive vibration.

(4) Please use the products immediately after the

package is opened, because the characteristics may

be reduced in quality and/or be degraded in

solderability due to storage under poor condition.

(5) Please do not drop the products to avoid cracking of

ceramic element.

4. Other

Please be sure to consult with our sales representative or

engineer whenever the products are to be used in

conditions not listed above.

o Rating

The component may be damaged if excessive mechanical

stress is applied.

P05E.pdf

Nov.24,2011

28

• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
