28 / 60 page ![]() ADP5050 Data Sheet Rev. 0 | Page 28 of 60 I2C INTERFACE TIMING DIAGRAMS Figure 59 shows the timing diagram for the I2C write operation. Figure 60 shows the timing diagram for the I2C read operation. The subaddress is used to select one of the user registers in the ADP5050. The ADP5050 sends data to and from the register specified by the subaddress. SCL CHIP ADDRESS SDA A0 A1 A2 A3 A4 A5 A6 A0 A1 A2 A3 A4 A5 A6 A7 0 0 0 0 1 0 0 1 D0 D1 D2 D3 D4 D5 D6 D7 SUBADDRESS WRITE DATA R/W NOTES 1. MAXIMUM SCL FREQUENCY IS 400kHz. 2. NO RESPONSE TO GENERAL CALLS. OUTPUT BY PROCESSOR OUTPUT BY ADP5050 Figure 59. I2C Write to Register SCL CHIP ADDRESS SDA A0 A1 A2 A3 A4 A5 A6 A0 A1 A2 A3 A4 A5 A6 A7 0 0 0 0 1 0 0 1 1 0 0 0 1 0 0 1 D0 D1 D2 D3 D4 D5 D6 D7 SUBADDRESS CHIP ADDRESS READ DATA NOTES 1. MAXIMUM SCL FREQUENCY IS 400kHz. 2. NO RESPONSE TO GENERAL CALLS. OUTPUT BY PROCESSOR OUTPUT BY ADP5050 R/W A0 A1 A2 A3 A4 A5 A6 R/W Figure 60. I2C Read from Register |
|
