Ramp/Soak Process Controller

E5CK--T

A--183

J Option Board Ratings and Characteristics

Model

Description

Specifications

E53-CKB

Event input

Contact input:

ON: 1 k

Ω max., OFF: 100 kΩ min.

No-contact input:

ON: residual voltage 1.5 V max., OFF: leakage current 0.1 mA max.

E53-CK01

Communications

RS-232C

Transmission method: Half-duplex

Synchronization method: Start-stop synchronization (asynchronous method)

E53-CK03

RS-485

Synchronization method: Start-stop synchronization (asynchronous method)

Baud rate: 1.2/2.4/4.8/9.6/19.2 kbps

E53-CKF

Transfer output

4to20mA:

Permissible load impedance: 500

Ω max.

Resolution: approx. 2,600 steps

Note: Event input is used for switching the pattern number, run or reset command, or automatic and manual mode with an external signal

input.

Temperature Ranges

Platinum Resistance Thermometer

Input (switch selectable)

JPt100

Pt100

Range

°C

--199.9

° to 650.0°

--199.9

° to 650.0°

°F

--199.9

° to 999.9°

--199.9

° to 999.9°

Resolution

°C/°F (main setting and alarm)

0.1

0.1

Thermocouple

Input (switch

selectable)

K1

K2

J1

J2

T

E

L1

L2

U

N

R

S

B

W

PLII

Range

°C

--200

to

1,300

0.0 to

500.0

--100

to 850

0.0 to

400.0

--199.9

to

400.0

0to

600

--100

to 850

0.0 to

400.0

--199.9

to

400.0

--200

to

1,300

0to

1,700

0to

1,700

100 to

1,800

0to

2,300

0to

1,300

°F

--300

to

2,300

0.0 to

900.0

--100

to

1,500

0.0 to

750.0

--199.9

to

700.0

0to

1,100

--100

to

1,500

0.0 to

750.0

--199.9

to

700.0

--300

to

2,300

0to

3,000

0to

3,000

300 to

3,200

0to

4,100

0to

2,300

Resolution

°C/°F(main

setting, alarm)

1

0.1

1

0.1

0.1

1

1

0.1

0.1

1

1

1

1

1

1

Note: 1. Setting number is factory-set to 2 (K1).

2. Thermocouple W is W/Re 5-26 (tungsten rhenium 5, tungsten rhenium 26).

Current/Voltage

Input (switch selectable)

Current input

Voltage input

4to20mA

0to20mA

1to 5 V

0to 5 V

0to 10V

Range

One of following ranges depending on results of scaling

--1999 to 9999

--199.9 to 999.9

--19.99 to 99.99

--1.999 to 9.999

Resolution (main setting and alarm)

Depends on range selected
