ADP196

Data Sheet

Rev. 0 | Page 6 of 12

TYPICAL PERFORMANCE CHARACTERISTICS

VIN = 1.8 V, VEN = VIN, CIN = COUT = 1 µF, TA = 25°C, unless otherwise noted.

0.014

0.012

0.010

0.008

0.006

0.004

0.002

–40 –30 –20 –10

TEMPERATURE (°C)

0.2V

1.0V

3.0V

5.5V

Figure 5. RDSON vs. Temperature, IOUT = 50 mA, Different Input Voltages (VIN)

0.016

0.014

0.012

0.010

0.008

0.006

0.004

0.002

–40 –30 –20 –10

TEMPERATURE (°C)

0.2V

1.0V

3.0V

5.5V

Figure 6. RDSON vs. Temperature, IOUT = 3 A, Different Input Voltages (VIN)

0.005

0.010

0.015

0.020

0.025

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

VIN (V)

50mA

100mA

200mA

500mA

1000mA

3000mA

Figure 7. RDSON vs. Input Voltage (VIN), Different Load Currents

0.005

0.010

0.015

0.020

0.025

0.030

0.035

0.040

0.045

0.050

VIN (V)

50mA

100mA

200mA

500mA

1000mA

3000mA

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

Figure 8. Voltage Drop vs. Input Voltage (VIN), Different Load Currents

–40

–5

TEMPERATURE (°C)

100mA

200mA

500mA

1000mA

3000mA

Figure 9. Ground Current vs. Temperature, Different Load Currents,

VIN = 1.8 V

–40

–5

TEMPERATURE (°C)

100mA

200mA

500mA

1000mA

3000mA

Figure 10. Ground Current vs. Temperature, Different Load Currents,

VIN = 3.3 V
