INTEGRATED CIRCUITS DIVISION

CPC7581

R06

www.ixysic.com

1.6 Switch Specifications

1.6.1

Break Switches, SW1 and SW2

Parameter

Conditions

Symbol

Minimum

Typical

Maximum

Unit

Off-state leakage current

+25° C

VSW (differential) = -320 V to gnd

VSW (differential) = +260 V to -60 V

ISW

0.1

A

+85° C

VSW (differential) = -330 V to gnd

VSW (differential) = +270 V to -60 V

0.3

-40° C

VSW (differential) = -310 V to gnd

VSW (differential) = +250 V to -60 V

0.1

RON

+25° C

ISW = ±10 mA, ±40 mA, RBAT and

TBAT = -2 V

RON

14.5



+85° C

20.5

-40° C

10.5

RON match

Per on-resistance test condition of

SW1, SW2.

Magnitude RON SW1-RON SW2

 R

0.15

0.8

DC current limit

+25° C

VSW (on) = ±10 V

ISW

300

+85° C

160

-40° C

400

425

Dynamic current limit

 0.5 s)

Break switches on, all other switches

off, apply ±1 kV at 10x1000

s pulse,

with appropriate protection in place.

-2.5

Logic input to switch output isolation

+25° C

VSW (TLINE, RLINE) = ±320 V, logic

inputs = gnd

ISW

0.1

A

+85° C

VSW (TLINE, RLINE) = ±330 V, logic

inputs = gnd

0.3

-40° C

VSW (TLINE, RLINE) = ±310 V, logic

inputs = gnd

0.1

dv/dt sensitivity

200

s
