INTEGRATED CIRCUITS DIVISION

www.ixysic.com

R06

CPC7581

1.3 Absolute Maximum Ratings

Absolute maximum electrical ratings are at 25°C.

Absolute maximum ratings are stress ratings. Stresses in

excess of these ratings can cause permanent damage to

the device. Functional operation of the device at these or

any other conditions beyond those indicated in the

operational sections of this data sheet is not implied.

Exposure of the device to the absolute maximum ratings for

an extended period may degrade the device and affect its

reliability.

1.4 ESD Rating

1.5 General Conditions

Unless otherwise specified, minimum and maximum

values are production testing requirements.

Typical values are characteristic of the device at 25°C

and are the result of engineering evaluations. They are

provided for informational purposes only and are not

part of the manufacturing testing requirements.

Specifications cover the operating temperature range

TA = -40°C to +85°C. Also, unless otherwise specified

all testing is performed with VDD = +5Vdc, logic low

input voltage is 0Vdc and logic high input voltage is

+5Vdc.

Parameter

Minimum Maximum

Unit

+5 V power supply (VDD)

-0.3

Battery Supply

-85

DGND to FGND Separation

-5

Logic input voltage

-0.3

VDD + 0.3

Logic input to switch output

isolation

-320

Switch open-contact

isolation (SW1, SW2, SW3)

-320

Switch open-contact

isolation (SW4)

-465

Operating relative humidity

Operating temperature

-40

+110

C

Storage temperature

-40

+150

C

ESD Rating (Human Body Model)

1000 V
