Sentinel RF Level Transmitter

804

30

2

Integral explosion proof

3

Remote explosion proof

5

Integral explosion proof w/IS safe probe circuit

6

Remote explosion proof w/IS safe probe circuit

Œ

0

120 VAC

1

240 VAC

2

24 VDC

INPUT POWER

1

4-20 mA

5

4-20 mA with RS-485 (Modbus)

ANALOG OUTPUT/COMMUNICATIONS

0

No relays

C

(2) 10 amp SPDT relays with gold flash contacts

D

(4) 10 amp SPDT relays with gold flash contacts

ALARM/CONTROL OUTPUT

R

NEMA 4X/7/9 aluminum, 1" NPT

Y

NEMA 4X/7/9 aluminum, 1" NPT with 316 SS, remote housing

ELECTRONIC HOUSING

MOUNTING

BASIC MODEL

M O D E L

N U M B E R

Models available for quick shipment, usually within one week after factory

receipt of a purchase order, through the Expedite Ship Plan (ESP).

P R O B E S

A full range of rigid and flexible probes, for conduc-

tive and non-conductive process media, is available

in various lengths and materials of construction. For

further information on probe assemblies, refer to

bulletin 50-125.

R E M O T E

C A B L E

Remote cable should be shielded, twisted pair, 22-gauge

stranded conductors and may be ordered using

Magnetrol part number 009-7146-001. Cable length in

feet must be specified at time of order; 2500 feet (760 m)

maximum; 800 feet (240 m) maximum for intrinsically

safe models.

Œ

Not available with Electronic housing code Y
