5 / 8 page

Flexible Probe

2 Holes

.38 (10) Dia.

1/2" NPT

or 3/4" NPT

3.00

(76)

2.00

(51)

2.37

(60)

3.50

(89)

Rotation

clearance

plugged

Optional

mounting

flange

.1875 (5)

.2500 (6)

2.95

(75)

2.75

(70)

3/4" NPT

3.00

(76)

4.63

(118) Dia.

4.67

(119)

Conduit

Connections

NEMA 4X/7/9

(remote probe housing)

⁄4" NPT

Single conduit

NEMA 4X/7/9

1" NPT

Dual conduit

NOTES:

Allow 8.00 (200) overhead clearance for cover removal.

Standard process connection is 3⁄

" NPT. Consult probe bulletin (50-125) for

flange and other probe connections.

Probe/amplifier connecting cable to be shielded, twisted pair, 22-gauge stranded

conductors, Magnetrol part number 009-7146-001; 2500 feet (760 m) maximum;

800 feet (240 m) maximum for intrinsically safe models.

Outline Dimensions

Standard Rigid Probe

Flexible Probe

Housing

NEMA 4X/7/9

3.87

5.93

10.89

2.44

13.44

4.11

12.33

4.71

13.44

4.11

Aluminum

(98)

(151)

(276)

(61)

(341)

(104)

(313)

(119)

(341)

(104)

Remote Mount

D I M E N S I O N A L

S P E C I F I C A T I O N S

( c o n t . )

I N C H E S

( m m )
