ADL5380

Rev. 0 | Page 5 of 36

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage: VCC1, VCC2, VCC3

5.5 V

LO Input Power

13 dBm (re: 50 Ω)

RF Input Power

15 dBm (re: 50 Ω)

Internal Maximum Power Dissipation

1370 mW

θJA1

53°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +125°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION

1 Per JDEC standard JESD 51-2. For information on optimizing thermal

impedance, see the Thermal Grounding and Evaluation Board Layout

section.
